Probest PTU-800 Turbidity Online Analyzer (0.01–100 NTU, 0.01–4000 NTU)
Manufacturer: Probest Model: PTU-800 P/N: 90268090 - Contact
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222)730.39.68
HCM city: (028) 38.119.636
Measurement range: 0.01-100 NTU,0.01-4000 NTU
Measurement accuracy: <±2% of the measured value or ±0.1NTU,the bigger one
Resolution: 0.01-0.1NTU,base on range
Repeatability: ±2%
Pressure range: ≤0.4Mpa
Flow rate: ≤2.5m/s,8.2ft/s
Calibration: Sample calibration, Slope calibration
Main material
Body:SUS316L(fresh water),Titanium alloy (marine);
Cable:PUR
Power supply: AC:85-500VAC ; DC:9-36VDC
Output: 3-way 4-20mA
Relay: Three-way relays, programmed response parameter and response value.
Communication protocol: MODBUS RS485
Measuring temperature: 0-45℃(Non-freezing)
Dimension: Sensor:Dia. 60mm*L261mm;Transmitter:145*125*162mm(L*W*H)
Weight: Sensor:1.65KG;Transmitter:1.35KG
Protective rate: Sensor:IP68/NEMA6P;Transmitter:IP66/ NEMA4X
Cable length: Standard:10m,the maximum may be extended to 100m
