Senseca DX 210-2.5hPa-00-L01-00 Digital differential pressure sensor with hose connection for gases (-2.500 ... +2.500 mbar)

Accuracy: ±0.5 %FS @ 25 °C

Applications: Only air and non-aggressive dry gases

Burst pressure:  6 x FS

Compensated temperature: 0…+50 °C

Connection (to meter): 4-pole M12

Connection (to process): For ⌀ 6x1 mm (internal ⌀ 4 mm) and ⌀ 8x1 mm (internal ⌀ 6 mm) hoses. 2 inputs for differential probes, 1 input for absolute probes

Dimensions: ⌀ 21.7 x 62 mm

Long-term stability: < 1 %FS / year

Material: Stainless steel

Operating conditions: -25…+85 °C / 0…95% RH non-condensing

Output: UART (TTL 3.3V)

Overall error: ±2.5 %FS over the whole compensated temperature range

Overpressure: 3 x FS

Power supply: 3.3 ... 6 Vdc

Protection degree: IP65

Storage temperature: -40…+125 °C

Warm-up time: 2.3 ms

Weight: 74 g approx.

Measuring range: -2.500 ... +2.500 mbar

Cable connection: M12A connector, 4-pin

Calibration: Factory adjustment with test protocol

Compensated temperature range: 0 ... +50 °C

Housing: Stainless steel

Option: 1 m PVC connection cable M12

Pressure connection: 2x connection for tube 6x1 mm (4 mm inner) or 8x1 mm (6 mm inner), differential

Protection: type IP65

Version: Interchangeable without loss of accuracy

Working temperature: -25 ... +85 °C
