Metrix DOX2025 数字示波器(25Mhz,2通道,500Ms / s)

Model: DOX2025
Manufacture: Metrix
warranty: 12 months

Type of display 7-inch TFT LCD colour screen (resolution 480x234)/Brightness and contrast adjustments
Display of the traces on screen Trace zone, 8x18 divisions/2 traces + reference + Maths function - Complete graticule or borders
Display mode - Samples or Vectors with interpolation, or Persistence Mode
Commands Usual direct commands by buttons/knobs on front panel/System of menus on right side of the screen with selection by
5 buttons next to them – "Menus On/Off" and "Print" commands
Choice of language By menu, 5 languages (FR/EN/DE/IT/ES), on-line help in English
Bandwidth 25 MHz
Number of channels 2 channels, common earths
Impedance 1MΩ/18 pF and External Trig channel
Display of the traces Channel number, earth reference indicator, and trace in the colour of the channel
Maximum input voltage ± 300 Vp-p (without probe)
Vertical sensitivity 12 ranges, from 2 mV to 10 V/div – Basic accuracy ±3%
Sources / Modes CH1, CH2, Ext, Ext/5, mains /Automatic, Triggered, Single - XY
Roll mode from 100 ms/div. to 50 s/div.
Type Front, pulse width (20ns-10s), video (PAL, SECAM, NTSC), slope, alternate
Coupling AC, DC, HFR (HF rejection), LFR (LF rejection)
AUTOSET AUTO Adjustment of the amplitude, the time base, and the triggering position
MATH functions on the channels Trace calculated in "real time": CH1 and CH2: addition, subtraction, multiplication, division
FFT analyzer FFT calculated on 1024 points/Simultaneous display of trace + FFT/4 windows (rectangle, Hamming, Hanning, Blackman)
Manual measurement cursors Manual, tracking, and automatic modes
PASS/FAIL Pass/Fail test using a limit envelope
RECORDER Slow signal recording mode >100ms (ROLL, 6M points)
Automatic measurements 32 time or level measurements
Probe calibration signal YES
