METONE 020D Wind Directon Sensor (0~357°; 0~360°)

Performance Characteristics

Azimuth:

  • Electrical: 0~357°

  • Mechanical: 0~360°

Threshold: 0.5mph (0.22m/s)

Linearity: ±1/2% of full scale

Accuracy: ±3°

Resolution: <0.1°

Damping Ratio: Standard 0.6 (magnesium tail) (meets EPA specifications)

Delay Distance: Less than 3ft (91cm)

Temperature Range: -50~65°C (-58~149°F)


Electrical Characteristics

Power Requirements: 12VDC at 10mA, 12VDC at 350mA for internal heater

Output Signal: 0~5, 0~2.5 (optional 0~1) VDC for 0~360°

Output Impedance: Ω maximum


Physical Characteristics

Weight: 1.5Ibs (0.68kg)

Finish: Clear anodized aluminum


Cable & Mounting

PN 1957: Cable Assembly; specify length in feet or meters PN 191-1

Mounting: Crossarm Assembly
