MATRIX MPS-6033X Multi-channel DC Power Supply

Rated output:

+ Voltage: 0 ~ 61V * 2/0 ~ 6V * 1

+ Electric current: 0 ~ 3A * 3

Load regulation:

+ Voltage: ≤0.01%+  3mV

+ Electric current: ≤0.01%+  3mA

Power regulation:

+ Voltage: ≤0.01%+  3mV

+ Electric current: ≤0.01%+  3mA

Set resolution:

+ Voltage: 1mV

+ Electric current: 1mA

Readback resolution:

+ Voltage: 1mV

+ Electric current: 1mA

Set accuracy:

+ Voltage: ≤0.03%+  10mV

+ Electric current: ≤0.1% + 5mA

Readback accuracy:

+ Voltage: ≤0.03%+  5mV

+ Electric current: ≤0.1% + 8mA

Ripple and noise:

+ Voltage rms: ≤2mVrms

+ Electric current: ≤5mArms

Series and parallel setpoint accuracy:

+ Voltage: ≤0.02%+  5mV

+ Electric current: ≤0.1%+  30mA

Memory:

+ Store / Call: 40 groups

+ Features: Timing off output

Timer: time setting: 0.1s ~ 99999.9s

Resolution: 0.1s

Operating temperature: 0 ~ 40 ° C

Bare metal size (mm): 255 * 110 * 380

Packing size (mm): 325 * 210 * 475

Net weight (kg): 8.5

Gross weight (kg): 10
