Initial load of Rockwell: 3kgf(29.42N)
Total load of Rockwell: 15Kgf(147.1N) 30Kgf(294.2N) 45Kgf(441.3N)
Rockwell Scale: HR15N HR30N HR45N HR15TW HR30TW HR45TW
Hardness testing range: HR15N:70-94 HR30N:42-86 HR45N:20-77 HR15TW:67-93 HR30TW:29-82 HR45TW:10-72
Dwell time: 0-60s
Resolution of hardness value: 0.1HR
Load value error: <1.0%
Hardness reading: LCD display
Screen size: 8 inch
Data Storage: Can store 60 kinds of test results, built-in printer, RS-232 interface, optional USB flash disk automatically stored
Conversion Scale: Superficial Rockwell, Brinell, Vickers
Carried Standard: BSEN 6508, ISO 6508, ASTM E18, GB/T230
Max Height of Specimen: 200mm
Distance from the center to the outer wall of the indenter: 160mm
Overall Dimensions : 560×200×800mm
Weight: 70kg
Power supply: AC220+5%,50~60Hz
