Optical system(nm): Littrow type optic system with 1200 grooves/mm diffraction grating monochromator.
Measurement Path length: 100mm
Spectral slitwidth(nm): 2nm
Wavelength range(nm): 190-1100
Wavelength accuracy(nm): ±0.5nm (System Auto Calibration)
Wavelength Repeatability: 0.2nm
Stray light: < 0.1%T (at 220nm and 340nm)
Photometric mode: T, A, and C measurement
Photometric Range: 0-125.0%T, -0.097-3.000A
Photometric accuracy: ±0.3%T
Photometric Repeatability: 0.15%T
Stability: <0.001A/hr (at 500nm, after warming up for 1 hour)
Baseline flatness ±0.002A
Main Specification:
Display: 128*64 LCD Displayer
Light Source: 6V10W Halogen Lamp(2000 hours); Deuterium lamp(1000 hours)
Sample Compartment: 100mm Optical Path
Standard Cell Holder: 10mm
Standard Cell Configuration: 10mm Glass cell(4pcs)
Power Requirement: 110/220VAC; 50/60Hz, ±10%
