CEM DT-972 专用自动参数分析仪 (True RMS, DC 1000V, DC/AC 10A)

Function: Max. Range - Max.Resolution - Basic Accuracy

Voltage DC: 1000V  ;  10µV  ;  ±0.03% (972/973)

Current DC: 10A  ;  0.01µA  ;  ±1.0%

Current AC: 10A  ;  0.01µA  ;  ±1.0%

Resistance: 60MΩ  ;  10mΩ  ;  ±1.5%

Duty Cycle: 99.9%  ;  0.1%  ;  ±1.2

Frequency: 10MHz  ;  0.001Hz  ;  ±0.1%

Capacitance: 60mF  ;  10PF  ;  ±3.5%

Temperature

-50ºC to 1300ºC 0.1ºC/ºF ±1.0%

-58ºF to 2372ºF

Diode Check: Test current <0.5mA MAX 3V

Continuity Test

Display: Negativity LCD Dispay

Accessories:

Test leads, 9V battery, Type K temperature probe, gift box with carrying case and Software
