Acepom ACEPOM312 Unibody Vibration Meter (0.1~199.9m/s², 0.1~19.9m/s, 0.001~1.999mm)

Probe: Piezoelectric shear acceleration probe

Measurement range:

     Acceleration: 0.1~199.9m/s²

     Velocity: 0.1~19.9m/s

     Displacement: 0.001~1.999mm

Accuracy: ±10%H±2digits

Frequency range:

     Acceleration: 10Hz~1kHz(LO); 1kHz~15kHz(HI)

     Velocity: 10Hz~1kHz

     Displacement: 10Hz~1kHz

Display: 3-1/2digital display, refresh per second, push MEAS to measure,release to hold

Singnal Output: AC,full range is 2V access to headphone VP-37

Power: continously work 25h with one 9V battery

Environment: -10~50℃,<90%RH

Size: 185(H)×68(H)×30(D) mm

Weight: 250g

Acessories:

     Short lever S: 1

     Long lever: 1

     Belt: 1

     Battery: 1

     Manual: 1
