Mahr 4157144DKS Digital Micrometer (40 EWRi-S, 75-100mm, IP65)

Standard: DIN 863-3

Measuring range mm: 75-100mm

Measuring range inch: 3-4"

Material Contact surface: hardened steel

Resolution mm/inch: 0.001 / .00005"

Error limit µm: 5 µm

Battery type: CR 2032 (3V Lithium)

Spindle diameter: 6.5 mm

Spindle thread pitch_mm: 5 mm

Measuring force (N)": 5 - 10

Details

Dimensions: a 73 mm | b 17 mm | c 132.5 mm |

Dimensional drawing 1

Brochure


Instruction
